Item Data
Service
environment
corresponding to
the IUA link set
client
IUA link
parameter
IUA link ID 15
Local port ID 1401
Local IP address 10.13.4.116/16 (It must exist in the signaling IP
address pool.)
Remote port ID 1400
IP address of the
primary MGC
10.14.1.2/16 (IP address of the primary MGC)
MGC that is bound
to the IUA link
primary-mgc
Priority of the IUA
link.
3
IP address of the
primary MGC
10.14.1.2/16 (IP address of the primary MGC)
ISDN BRA port Subrack ID/Slot
ID/Port ID
0/3/1
IUA interface ID 10
Working mode P2MP
TID 106
Phone number 88880000
Procedure
Step 1 Configure the working mode of the ISDN BRA port.
In the BRA port mode, configure the working mode of the ISDN BRA port to P2MP, configure
the activation mode to stable activation, and enable automatic activation.
huawei(config)#braport
huawei(config-braport)#braport attribute set 0/3/1 workmode p2mp autodeactive
enable
Step 2 Add an IUA link set and IUA links.
In the SIGTRAN mode, configure the SIGTRAN protocol stack. Add an IUA link set, and then
add IUA links.
huawei(config-braport)#quit
huawei(config)#sigtran
huawei(config-sigtran)#iua-linkset add 1 mgid 0 jointly-work enable trafficmode
override
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
337

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
