Huawei SmartAX MA5608T User Manual

Config
uration
Item
Data Remarks
Internet access VoIP IPTV
DHCP
relay
-
l Number of the
DHCP server
group: 1
l IP address of
DHCP server
group 1:
20.1.1.2
l IP address of
DHCP server
group 2:
20.1.1.3
l IP address of
the VLAN
Layer 3
interface:
10.1.1.1/24
l Number of the
DHCP server
group: 2
l IP address of
DHCP server
group 1: 20.2.2.2
l IP address of
DHCP server
group 2: 20.2.2.3
l IP address of the
VLAN Layer 3
interface:
10.2.2.1/24
-
Multicas
t
- -
l Multicast mode:
IGMP Proxy
l Profile 0 of
multicast user 2:
the right to watch
only program
BTV-1
l Multicast
upstream port:
0/19/0
l Multicast IP
address of
program BTV-1:
224.1.1.1;
program source IP
address:
10.10.10.10
l Multicast IP
address of
program BTV-2:
224.1.1.2;
program source IP
address:
10.10.10.10
-
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
375

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
