Table 4-2 Data plan for configuring the VLAN stacking wholesale service
Item Data Remarks
VLAN VLAN ID:
l ISP1: 60
– Enterprise user 1: 11
– Enterprise user 2: 12
l ISP2: 61
– Enterprise user 3: 11
– Enterprise user 4: 12
l VLAN type: smart VLAN
l VLAN attribute: stacking
The outer VLAN identifies the
ISP, and inner VLAN
identifies the user. The inner
VLAN tags must be unique
under the same ISP, but can be
the same under different ISPs.
Upstream
port
0/19/0 -
Traffic
profile
l Traffic profile ID: 10
l CIR: 2 Mbit/s
l Priority copy policy: user-cos
l Default 802.1p priority of the packet: 4
l Priority-based scheduling policy of the
downstream packets: local-setting
The CIR depends on the user
bandwidth requirement.
ADSL2+
port
l ADSL2+ port ID
– Enterprise user 1: 0/2/0
– Enterprise user 2: 0/2/1
– Enterprise user 3: 0/3/0
– Enterprise user 4: 0/3/1
l Default ADSL2+ line profile: 1
l Default ADSL2+ alarm profile: 1
-
Service
virtual port
l Service port ID:
– Enterprise user 1: 0
– Enterprise user 2: 1
– Enterprise user 3: 2
– Enterprise user 4: 3
l VPI: 0
l VCI: 35
l ID of the traffic profile in Rx direction: 10
l ID of the traffic profile in Tx direction: 10
l The VPI/VCI is the same as
the management VPI/VCI
on the peer modem.
l The traffic profile that
meets the service
requirement is used.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
4 Configuration Example of the Private Line Service
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
396
