Item service Type Remarks
UBR VBR CBR
Initial
Value
for
Ingress
PVC in
the PW
0/32 0/33 0/34 Since the VPI/VCI parameters of
cells on PVCs at different ports are
the same, the VPI/VCI parameters
must be changed once before the
cells on client-side PVCs are
encapsulated into PWs. This
ensures that the VPI/VCI
parameters are unique for cells on
each PVC in the PW.
Initial
Value
for
Egress
PVC in
the PW
1/32 1/33 1/34
Egress
Label
of the
PW
8450 8451 8452
Ingress
Label
of the
PW
8460 8461 8462
PW
CAR
12288
Kbit/s
30720
Kbit/s
6144 Kbit/s QoS policies:
In the upstream direction,
priorities of service packets are
remarked by setting CAR and PIR
for the PW and only yellow
packets are identified (CAR < Rate
< PIR).
User-
CoS
Priority
1 4 5
CoS
Priority
After
Remar
king
0 2 5
WRED
Profile
ID: 5 ID: 5 ID: 5 QoS policies:
In the downstream direction, the
xDSL board sets CoS drop
threshold globally to early drop
yellow packets.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 4 Configuration Example of the Private Line Service
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
403
