Huawei SmartAX MA5608T User Manual

Procedure
Step 1 (Optional) Configure the working mode of the board.
Configure the working mode of the board to voice.
NOTE
The working sub-mode of the board can be configured only when the working mode of the board is configured
to voice. By default, the working mode of the board is voice.
huawei(config)#interface edt 0/3
huawei(config-edt-0/3)#board workmode voice
Step 2 Configure the working sub-mode of the board according to service requirements.
l If the entire board is used for transparently transmitting the narrowband data private line
service, configure the working sub-mode of the board to transparent.
huawei(config-edt-0/3)#runmode transparent
huawei(config-edt-0/3)#quit
l If a specified port is used for transparently transmitting the narrowband data private line
service, configure the working sub-mode of the board to service and the running mode of
the port to transparent.
huawei(config-edt-0/3)#runmode service
huawei(config-edt-0/3)#e1port runmode 0 transparent
huawei(config-edt-0/3)#quit
NOTE
l Before changing the service mode to transparent mode, make sure that no service is configured for the board.
l In the transparent mode, the E1 ports and SHDSL ports are in one-to-one mapping, that is, ports 0-15 map
ports 16-31 one by one.
Step 3 Save the data.
huawei(config)#save
----End
Result
The user can normally access the DDN network by using the MA5600T/MA5603T/
MA5608T.
Configuration File
If the entire board is used for transparently transmitting the narrowband data private line service:
interface edt 0/3
board workmode voice
runmode transparent
quit
save
If E1 port 0 is used for transparently transmitting the narrowband data private line service:
interface edt 0/3
board workmode voice
runmode service
e1port runmode 0 transparent
quit
save
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
4 Configuration Example of the Private Line Service
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
432

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
