6. Bind the alarm threshold profile.
huawei(config-if-gpon-0/18)#ont alarm-profile 1 0 profile-id 1
7. Bind the DBA profile.
huawei(config-if-gpon-0/18)#tcont bind-profile 1 0 1 profile-id 10
8. Divide the ONT port VLAN.
huawei(config-if-gpon-0/18)#ont port vlan 1 0 eth 10 0
huawei(config-if-gpon-0/18)#ont port native-vlan 1 0 eth 1 vlan 1510
9. Configure the GEM port.
huawei(config-if-gpon-0/18)#gemport add 1 gemportid 150 eth
10. Bind the GEM port to an ONT T-CONT.
NOTE
In the actual application, if the ONT terminal does not support the priority queue scheduling, you can use
the CAR to limit the rate when binding the GEM port to the ONT T-CONT.
huawei(config-if-gpon-0/18)#ont gemport bind 1 0 150 1 priority-queue 3
11. Create the mapping between the GEM port and the service stream.
huawei(config-if-gpon-0/18)#ont gemport mapping 1 0 150 vlan 1510
12. Add the service port.
huawei(config-if-gpon-0/18)#quit
huawei(config)#service-port vlan 1510 gpon 0/18/0 gemport 150 multi-service
user-vlan 10 rx-cttr 5 tx-cttr 8
Step 11 Configure the POTS service.
1. Configure the upstream ports of the media stream and the signaling flow.
huawei(config)#vlan 1600 smart
huawei(config)#port vlan 1600 0/19 0
huawei(config)#interface vlanif 1600
huawei(config-if-vlanif1600)#ip address 10.176.6.33 24
huawei(config-if-vlanif1600)#quit
2. Configure the static route destined to the MGC.
NOTE
When the MGC and the MG are in the same network segment, you do not need to configure the static
route.
huawei(config)#ip route-static 10.30.80.0 255.255.255.0 10.176.6.62
3. Configure the media IP address pool and the signaling IP address pool.
huawei(config)#voip
huawei(config-voip)#ip address media 10.176.6.33 10.176.6.62
huawei(config-voip)#ip address signaling 10.176.6.33
huawei(config-voip)#quit
4. Configure the MG interface.
Add an MG interface.
huawei(config)#interface h248 0
Are you sure to add MG interface? (y/n)[n]:y
Configure the MG interface attributes.
huawei(config-if-h248-0)#if-h248 attribute mgip 10.176.6.33 mgport 2944 code
text
transfer udp primary-mgc-ip1 10.30.80.65 primary-mgc-port 2944 mg-media-ip1
10.176.6.33
Configure the software parameters of the MG interface (in this example, only parameter
20 is configured, and other parameters use the default values).
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
5 Configuration Example of MSTP Subtending Network
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
452
