Network
ing
Scenario
Description OLT Device
(Main Control Board
+Service Board
+Upstream Board)
ONT Device
9.7.1
Bridging
+Voice
ONT
Network
Scenario
The ONT integrating an
integrated access device
(IAD) provides Internet,
VoIP, and IPTV services to
users.
The bridging+voice ONT
provides Layer 2 data and
voice services. This scenario
provides transparent
transmission channels and
requires simple service
configuration, so this
scenario applies to Layer 2
networking.
l For data services, a PC
directly performs dial-
up. Then, the upper-layer
broadband remote access
server (BRAS) device
authenticates and
accesses the PC. The PC
can also access the
Internet using the
Dynamic Host
Configuration Protocol
(DHCP) or static IP
address.
l The ONT with a built-in
voice module
encapsulates voice
service packets, and the
OLT transmits them to
the upstream next
generation network
(NGN) or IP multimedia
subsystem (IMS).
l H801SCUN/
H802SCUN
+H805GPBD/
H806GPBH/
H802GPBD
+H801GICF/
H801GICG/
H801X2CS
l H801SCUH
+HG802GPFD
+H801GICD/
H801GICE/
H801X2CS
l H801MCUD
+H805GPBD/
H806GPBH/
H802GPBD
(no upstream board
is configured and
H801MCUD is used
as the control board
for upstream
transmission)
For supported ONTs
in different scenarios,
see 9.5 Reference of
GPON ONT
Capability Sets.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
550
