Prerequisites
l The OLT is connected to the BRAS.
l Related configurations are performed on the BRAS according to the authentication and
accounting requirements for dialup users. For details about the configuration, see the
configuration guide.
l The ONT has been added to the OLT. For details, see 9.7.1.3 Adding an ONT to an
OLT.
l The VLAN of the LAN switch port connected to the OLT is consistent with the upstream
VLAN of the OLT.
Data Plan
Item Data
ONT line profile Profile name: ftth
T-CONT ID: 4
GEM port ID for Internet access service: 14
Network topology data Upstream port: 0/19/0
PON port: 0/1/0
ONT IDs: 1 and 2
ID of the port on the ONT that is connected to the PC: 1
VLAN Plan Double-tagged VLAN:
l S-VLAN ID: 100
l S-VLAN type: smart
l S-VLAN attribute: stacking
l CVLAN ID: 1001
l C'-VLAN ID: 1010-1011
VLAN Translation Policy:
l ONT: ONTs configure the VLAN and add the same C-
VLAN tag to packets. All ONTs are in the same C-
VLAN.
l OLT: The OLT performs VLAN translation: C<->S+C'.
The C'-VLAN of every ONT differs from each other.
Procedure
l Configure the OLT.
1. Configure a traffic profile.
Run the display traffic table ip command to query existing traffic profiles in the
system. If the traffic profiles existing in the system do not meet the requirements, you
need to run the traffic table ip command to add a traffic profile.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
586
