Table 1-16 Data plan for the outband management through SSH in a LAN
Item Data
Maintenance Ethernet port of the MA5600T/
MA5603T/MA5608T
l IP address: 10.50.1.10/24
l User authentication mode: RSA public
key authentication
l RSA key name: key
NOTE
By default, the IP address of the maintenance
Ethernet port (ETH port on the control board) is
10.11.104.2, and the subnet mask is
255.255.255.0.
New user
l User name/Password: huawei/test01
l Authority: Operator
l Permitted reenter number: 4
Maintenance terminal IP address: 10.50.1.20/24 (in the same subnet
as the IP address of the maintenance Ethernet
port)
Table 1-17 Data plan for the outband management through SSH in a WAN
Item Data
Maintenance Ethernet port of the MA5600T/
MA5603T/MA5608T
l IP address: 10.50.1.10/24
l User authentication mode: RSA public
key authentication
l RSA key name: key
NOTE
By default, the IP address of the maintenance
Ethernet port (ETH port on the control board) is
10.11.104.2, and the subnet mask is
255.255.255.0.
New user
l User name/Password: huawei/test01
l Authority: Operator
l Permitted reenter number: 4
Maintenance terminal IP address: 10.10.1.10/24
Router port connecting to the MA5600T/
MA5603T/MA5608T
IP address: 10.50.1.1/24
Flowchart
Figure 1-25 shows the flowchart for logging in to the MA5600T/MA5603T/MA5608T through
SSH.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
40
