l The ONT has been added to the OLT. For details, see 9.7.1.3 Adding an ONT to an
OLT.
l Different voice services require different ONT software versions. Before the configuration,
ensure that the current ONT software version supports SIP. For details, see relevant ONT
manuals.
l The ONT software version of the SIP voice service can be configured as V100R002C04
or later through the CLI.
Data Plan
Item Data
ONT line profile Profile name: ftth
T-CONT ID: 4
GEM port ID: 12
VLAN Plan Single VLAN tag:
l SVLAN ID: 200
l SVLAN type: smart
l SVLAN attribute: common
l CVLAN ID: 300
VLAN translation policy:
l ONT: VLANs are configured for the ONTs on the
same network in a unified manner, and the ONTs
have the same C-VLAN. The ONT adds a C-VLAN
tag to packets.
l OLT: translates the VLAN tag (C-VLAN <-> S-
VLAN).
Voice parameter
IP address of the SIP server: 200.200.200.200/24
Port ID of the SIP server: 5060
Home domain name: huawei.com
User phone number 1: 77730010
User phone number 2: 77730020
Procedure
Step 1 Configure a traffic profile.
Run the display traffic table ip command to query the existing traffic profiles in the system. If
the existing traffic profiles in the system do not meet the requirements, run the traffic table ip
command to add a traffic profile.
Step 2 Configure the mapping relationship between a GEM port and a VLAN.
The service flow of user VLAN 300 is mapped to GEM port 12 in the ONT line profile.
huawei(config)#ont-lineprofile gpon profile-name ftth
huawei(config-gpon-lineprofile-1)#gem mapping 12 2 vlan 300
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
693
