Item Data
Traffic profile ID: 8
802.1p priority: 4
CIR: off (unlimited)
Priority-based scheduling policy: local-setting
VLAN Plan Single VLAN tag:
l SVLAN ID: 1000
l MVLAN ID: 1000
l VLAN type: smart
l VLAN attribute: common
VLAN translation policy:
l ONT: duplicates multicast packets based on user ports
and MVLANs are stripped off downstream.
l OLT: duplicates multicast packets based on PON ports
with MVLAN unchanged.
Multicast service data
Multicast protocol: IGMP proxy
Multicast version: IGMPv2
Multicast program: dynamic obtaining mode
Procedure
Step 1 Configure the OLT.
1. Configure a traffic profile.
Configure traffic profile 8. Set the CIR to off (unlimited), priority to 4, and priority-based
scheduling policy to local-setting (that is, queues are scheduled based on the priority
specified in the profile).
NOTE
Run the display traffic table ip command to query the existing traffic profiles in the system. If the existing
traffic profiles in the system do not meet the requirements, run the traffic table ip command to add a
traffic profile.
huawei(config)#traffic table ip index 8 cir off priority 4 priority-policy
local-setting
2. Configure the mapping relationship between a GEM port and an Ethernet port on the ONT.
If the ONT is connected to the STB through Ethernet port 2, map the service flow of Ethernet
port 2 to GEM port 13 in the ONT line profile.
huawei(config)#ont-lineprofile gpon profile-name ftth
huawei(config-gpon-lineprofile-1)#mapping mode port
huawei(config-gpon-lineprofile-1)#gem mapping 13 1 eth 2
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
3. Configure the multicast forwarding mode.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
698
