Huawei SmartAX MA5608T User Manual

Parameter Access Distance Remarks
< 100 m < 300 m 300-500 m 500-800 m 800-1000 m
Maximum transmit
rate upstream
15 Mbit/s 15 Mbit/s 10 Mbit/s 5 Mbit/s 2 Mbit/s
noise ratio
(SNR)
margin for
the line and
therefore
enhances
its
capability
for
withstandin
g noise and
interferenc
e.
l The rates
can be
specified
using these
two
parameters
and also
can be
specified in
the traffic
profile.
When they
are
specified in
both ways,
the actual
activation
rate is
determined
by the
smaller
one.
Minimum INP
2 symbols 2 symbols 2 symbols 2 symbols 2 symbols None
Target SNR margin 8 dB 8 dB 8 dB 8 dB 8 dB None
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
749

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
