Networking
Scenario
Description Typical OLT or
Master Subrack
Configuration
ONU or Extended
Subrack Device
FTTB and
FTTC
Ethernet
Cascade
Networking
(ONU works
as an
independent
NE)
l ONUs are deployed in
corridors or fiber
distribution terminals
(FDTs) on the curb. They
connected to users
through twisted pairs.
l The networking between
the ONU and users is the
same as the xDSL
networking for a PON
network. The networking
applies in the following
scenarios:
– FTTB and FTTC
networking in xDSL
access mode, without a
home gateway (HGW)
– FTTB/FTTC+HGW
networking (The voice
service is provided
through the ONU.)
– FTTB/FTTC+HGW
networking (The voice
service is provided
through the HGW.)
MA5600T or
MA5603T:
l Control board:
SCUN or
SCUH
l Service board:
OPGD or
ETHB
l Upstream
interface board:
GICF, GICG,
X1CA, or
X2CA
ONU series
supporting GE
upstream
transmission. For
details, see 11.1.7
Ethernet Upstream
ONU Capability
Sets.
FTTB and
FTTC
Ethernet
Cascade
Networking
(ONU works
as a GE
remote
extended
subrack)
l Extended subracks are
deployed in corridors or
FDTs on the curb. They
connected to users
through twisted pairs.
l The networking applies to
high-bandwidth access
scenarios and provides the
high-speed Internet
access service, voice
service, and IPTV service.
In the scenarios, an HGW
is configured on the user
side and VDSL2 is used
for downstream
transmission.
MA5600T or
MA5603T:
l Control board:
SCUN
l Service board:
ETHB
l Upstream
interface board:
GICF, GICG,
X1CA, or
X2CA
MA5623AR
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
823
