Data plan
Item Data Remarks
Internet access
service
OLT VLAN ID:
l CVLAN ID: 256 x GPON
port ID + 32 x Split ratio x
(Splitter port ID - 1) + ONU
port ID + 1
l SVLAN: VLAN ID 100 and
attribute stacking
Upstream VLANs of the ONU:
1001-1016
Service flow ID: 101
Assume that the split ratio of the
optical splitter is 1:32, the ONU is
connected to port 1 on the optical
splitter using the optical cable, and
the user PC is connected to port 1
on the ONU. In this case, the inner
VLAN is 258 according to the
formula for calculating the inner
VLAN.
For details about the data plan, see
11.2.3 Principle of Internet
Access Service Data Plan.
VoIP service
OLT VLAN ID (VLAN
transparently transmitting the
ONU service): 200
ONU VLAN ID: 200
Service flow ID: 201
For details about the data plan, see
11.2.5 Principle of VoIP Service
Data Plan.
Procedure
l Configure the channel for the Internet access service.
1. Configure the service VLAN and add the upstream port to this VLAN.
Configure the SVLAN ID to 100, VLAN type to smart VLAN, and VLAN attribute
to stacking. Add upstream port 0/19/0 to VLAN 100.
huawei(config)#vlan 100 smart
huawei(config)#vlan attrib 100 stacking
huawei(config)#port vlan 100 0/19 0
2. Configure the corresponding traffic profile.
The 802.1p priority for the Internet access service is 0 and the traffic profile is
unlimited. You can run the display traffic table ip command to query the traffic
profile in the system. Use traffic profile 6.
huawei(config)#display traffic table ip from-index 0
3. Configure service flows to receive and transparently transmits the Internet access
service from the ONU.
According to the data plan,
– For the OLT: The SVLAN ID is 100, inner VLAN ID is 258. The user-side VLAN
ID of the OLT is the same as the upstream VLAN ID of the ONU, that is, 1001.
The Internet access service uses GEM port 12.
– For the ONU: The upstream VLAN ID is 1001.
huawei(config)#service-port 101 vlan 100 gpon 0/2/1 ont 1 gemport 12 multi-
service
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
866
