Huawei SmartAX MA5608T User Manual

CAUTION
This operation interrupts the ongoing services carried on the currently used MG interface. Hence,
exercise caution when performing this operation.
Data plan
For details about the data plan, see 11.2.5 Principle of VoIP Service Data Plan.
Item Data
MG
interface
data
NOTE
The data
configurati
on must be
the same as
the data
configurati
on on the
MGC.
Media
and
signalin
g
paramet
ers
Media and signaling
upstream VLANs
200
Media and signaling
upstream port
0/0/1
Media IP address and
signaling IP address
10.10.10.10/24
Default gateway IP address 10.10.10.1/24
MG interface ID 0
Signaling port ID 2944
IP address of the primary MGC 200.200.200.200/24
Port ID of the primary MGC 2944
Coding Text
Transmission mode UDP
H248 version that MG starts to
negotiate
1 (the negotiation starts from V1)
Voice user
configuratio
n data
Phone number 83110001-83110024
Terminal identification Terminal layering is not supported
and the terminal identification
ranges from 0 to 23.
User priority Cat2 for phone 1
Cat3 for phone 2 to phone 24
(default)
User type Common user (DEL user by default)
Common
parameter
System parameter Default value
Overseas parameter Default value
PSTN port attribute Polarity-reversal
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
909

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
