Huawei SmartAX MA5608T User Manual

Item Procedure Remarks
Configure the
management
channel
between the
OLT and the
ONU.
l Configure
the Internet
access
service
channel.
l Configure
the VoIP
service
channel.
l Configure
the VoD
service
channel
l Configure
the multicast
service
channel.
In the FTTB+HGW networking (ONU
provides the voice service), the ONU
provides the Internet and voice services and
the HGW provides the IPTV service.
Therefore, you need to create specific
service channels for various services on the
OLT.
ONU Configure the
Internet access
service.
Configure the
LAN Internet
access service
on the ONU.
NOTE
Different ONUs have different ports, including
LAN, ADSL2+, VDSL2, and VDSL2 vectoring
ports, for the Internet access. Select an
appropriate configuration method according to
the port type.
Configure the
ADLS2+
Internet access
service on the
ONU.
Configure the
VDSL2
Internet access
service on the
ONU.
(Optional)
Configure
vectoring on
the ONU
Configure the
VoIP service.
Configure the
H.248 -based
VoIP service on
the ONU.
NOTE
The H.248 and SIP protocols are mutually
exclusive for the VoIP service. Only one of them
is configured at a time.
Configure the
SIP-based
VoIP service on
the ONU.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
924

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
