Item Data Remarks
VPI/VCI of
ADSL2+
users in the
scenario in
which
HGWs are
connected
upstream to
an ONU in
ADSL2+
mode
VPI: 0
VCI: 35
Internet service providers (ISPs) provide VPI/
VCI information.
VDSL2
path mode
in the
scenario in
which
HGWs are
connected
upstream to
an ONU in
VDSL2
mode
PTM
Both the central office and HGWs must support
the PTM mode.
VLAN ID
of the VoD
service
300 The VoD service is a carrier-operating, closed
service and primarily adopts only SVLAN
tags, which are transparently transmitted by
OLTs.
Multicast
VLAN ID
of the ONU
1000 -
Multicast
VLAN ID
of HGWs
43 A carrier generally specifies a globally unique
multicast VLAN ID for HGWs.
Procedure
l Configure the VoD service.
Create VLAN 300 with the common attribute and add upstream port 0/0/1 to the VLAN.
huawei(config)#vlan 300 smart
huawei(config)#port vlan 300 0/0 1
Configure a traffic profile for the IPTV service.
The IEEE 802.1p priority of the IPTV service is 4, and rate limitation is not required. To
check whether any existing traffic profile meets the requirements, run the display traffic
table ip command. In this example, the query result shows that no traffic profile meets the
requirements, so a traffic profile needs to be configured.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
960
