IAI PCON-CB series User Manual

3. Wiring
3.3 Wiring Method
3-47
ME0342-4B
3.3.5 SIO Connector Connection
SIO connectors can be used not only for the connection of teaching tool, but also for the
connection of the host controller (PLC, touch panel and PC).
For the operation, refer to the instruction manual of each device.
Refer to [Configuration of Instruction Manual Related to PCON-CB at the beginning]
Caution
● If the controller is connected with a teaching tool, set the operation mode setting switch
to MANU.
● If the teaching pendant is removed with the power supply being on, the condition will
become the transient emergency stop and the operated actuator will stop.
Do not disconnect the teaching pendant during the operation.
● For CGB/CGFB/CGBP type, in case the teaching tool is not used, make sure to insert
the dummy plug “DP-5” to SIO connectors.
Teaching Pendant
D
ummy Plug: DP-5
PC
3.3 Wiring Method
ME0342-4B 3-48
3.3.6 Field Network Connector of PIO
For how to lay out cables for each field network, refer to the following instruction manuals to
proceed the work.
PCON-CB/CFB Type
Field Network Name Description Details
Supported models
CB/CFB CBP
CC-Link
Control of the actuator is
available with I/O
communication using the
control signals same as
those for PIO or the
numerical data
communication.
Refer to the other
ME0254
(Note1)
○ ○
CC-Link IE Field
Refer to the other
ME0389
(Note1)
○ ○
CompoNet
Refer to the other
ME0220
(Note1)
○ ○
DeviceNet
Refer to the other
ME0256
(Note1)
○ ○
EtherCAT
Refer to the other
ME0273
(Note1)
○ ○
EtherNet/IP
Refer to the other
ME0278
(Note1)
○ ○
MECHATROLINK-I/II
Refer to the other
ME0221
(Note1)
○ ○
PROFIBUS-DP
Refer to the other
ME0258
(Note1)
○ ○
PROFINET IO
Refer to the other
ME0333
(Note1)
○ ○
MECHATROLINK-III
Synchronized control of
several actuators in highly
constant periodicity is
available.
Refer to the other
ME0317
(Note1)
○ ×
RS485
Actuator is controlled with
using a general protocol
“Modbus” communication.
Refer to the other
ME0162
(Note1)
○ ○
Note 1 PCON- CB/CFB/CBP are the slave units (slave stations). Check the instruction manual
of the master unit of each supplier and PLC to be mounted for the details of each
network.
For the instruction of the field network for PCON-CB/CFB/CBP, the instruction manual
is provided separately. Use the manual together with this manual.
Note 2 PCON-CBP is not applicable for MECHATROLINK-III.
