2. Specications
2.1 Product Check
2-4 ME0342-4B
2.1.4 How to Read the Model
Shown below is how to read the model codes.
P C O N - C B - 2 0 P WAI - N P - 2 - 0 - A B - D N**
Note 1 The pulse train type (PLN/PLP) in PCON-CB/CGB/CFB/CGFB and PCON-CBP/CGBP are
not applicable for the simple absolute type.
Note 2 PCON-CBP/CGBP are not applicable for PLN, PLP and ML3.
<Series>
<Type>
CB : Standard Type
CGB : Safety Category Compliant Type
CFB : High Thrust Actuator Connected Type
CGFB : High Thrust Actuator Connected
Safety Category Compliant Type
CBP : Pulse pressing connectivity type
CGBP
: Pulse pressing connectivity
Safety Category Compliant Type
<Detail of Connected Axis>
[Motor Type]
20P : 20□ size pulse motor
20SP : 20□ size pulse motor
28P : 28□ size pulse motor
28SP : 28□ size pulse motor
35P : 35 size pulse motor
42P : 42□ size pulse motor
42SP : 42□ size pulse motor
56P : 56□ size pulse motor
56SP : 56 size high thrust pulse motor
60P : 60 size high thrust pulse motor
86P : 86□ size high thrust pulse motor
[Encoder Type]
WAI : Incremental/Battery-less Absolute Shared
SA : Simple Absolute
(Note 1)
<I/O Type>
(Note 2)
NP : NPN Specification (Sync. Type) (Standard)
PLN : Pulse Train NPN Specification
PN : PNP Specification (Source Type)
PLP : Pulse Train PNP Specification
CC : CC-Link Connection Type
CIE : CC-Link IE Field Connection Type
CN : CompoNet Connection Type
DV : DeviceNet Connection Type
EC : EtherCAT Connection Type
EP : EtherNet/IP Connection Type
ML : MECHATROLINK-/ Connection Type
PR : PROFIBUS-DP Connection Type
PRT : PROFINET IO Connection Type
ML3 : MECHATROLINK- Connection Type
<Identification for IAI use only>
* There is no identification in some cases
<
Type of Installation>
(Not Specified) : Screw Fixing Type
DN : DIN Rail Mounting Type
<Applicable to Simplified Absolute Unit>
(Note 1)
AB : Simple Absolute Type
(With the Absolute Battery)
ABU : Simple Absolute Type
(With the Absolute Battery
Unit (SEP-ABU))
ABUN : Simple Absolute Type
(With no Absolute Battery)
(Not Specified) : Incremental/Battery-less
Absolute
<Power
-supply Voltage>
0 : 24V DC
<I/O Cable Length>
0 : Equipped with no cable
2 : 2m (Standard)
3 : 3m
5 : 5m
