4. Operation
4.1 Basic Operation
4-8 ME0342-4B
4.1.3 Parameter Settings
Parameter data should be set to be suited to the system or application. Parameters are
variables to be set to meet the use of the controller in the similar way as settings of the ringtone
and silent mode of a cell phone and settings of clocks and calendars.
(Example for Parameter Setting)
Soft Stroke Limit : Set a proper operation range for definition of the stroke end, prevention
of interferences with peripherals and safety.
Zone Output : Set to require signal outputs in an arbitrary position zone within the
operation zone.
Parameters should be set to meet the use of the controller prior to operation. Once set, they
may not set every operation.
Refer to [Chapter 6 Parameter] for the parameter types and the details.
