3. Wiring
3.1 Positioner Mode (PIO Control)
3-1 ME0342-4B
3.1 Positioner Mode (PIO Control)
3.1.1 Wiring Diagram (Connection of Devices)
Caution
Make sure to turn the power to the controller OFF when inserting or removing the
connector that connects the PC software or teaching pendant to the controller.
Inserting or removing the connector while the power is turned ON causes a controller
failure.
Teaching Pendant
(to be purchased separately)
PC Software
(to be purchased separately)
Actuator
Host System
(PLC, etc.…Please prepare separately)
Power Source I/O Control
(24V DC
…
Please prepare separately)
Emergency Stop Circuit
Control/Driving Power Supply
(24V DC
…Please prepare separately)
