9. Appendix
9.4 List of Specifications of Connectable Actuators
9-128 ME0342-4B
9.4.3 Push Force / Gripping Force and Current Limit Value
Caution
● The correlation of the push force and the current limit value is the rated push speed (in
the setting at the delivery) and is a reference value.
● Use the actuator with the setting above the minimum push force value. The push force
will be unstable if it is below the minimum push force value.
● If the positioning speed setting in the operation condition is made lower than the push
speed, the push speed will follow that speed, thus cannot perform the expected push
force.
RCP6 Series (Slider type / Rod type / Table type)
* Characteristics should be the same for Cleanroom/Dust and drip proof type.
