2.2 Operation Modes and Functions
2-8 ME0342-4B
2.2.3 Pulse Train Control Mode (PCON-CB/CBP I/O Type: PLN and PLP)
Switching between the positioner mode and the pulse train control mode should be available in
the parameters for the pulse train control type (I/O type PLN and PLP) in PCON-CB.
There are two types of control systems in the pulse train control mode. Set the most suitable
PIO pattern in Parameter No. 25 "Select PIO Pattern".
Also, switching between the positioner mode and the pulse train control mode should be
available in the parameters for the pulse train control type of PCON-CB. There should be six
types of PIO patterns available to select from in accordance with the parameters in the
positioner mode.
Refer to [3.2.3 Wiring] for wiring in the pulse train control and [4.3 Pulse Train Control Mode] for
details of how to operate and the main features.
[1] PIO Patterns in Pulse Train Control Mode
Pattern
type
Value set in
Parameter
No.25
Mode Overview
PIO
pattern 0
0
Positioning mode
(Standard type)
Refer to [2.2.2 Positioner Mode (PCON-
CB/CBP I/O Type: NP and PN)]
PIO
pattern 1
1
Teaching mode
(Teaching type)
PIO
pattern 2
2
256-point mode (256-
point type)
PIO
pattern 3
3
512-point mode (512-
point type)
PIO
pattern 4
4
Solenoid valve mode 1
(7-point type)
PIO
pattern 5
5
Solenoid valve mode 2
(3-point type)
PIO
pattern 6
6
(Factory default)
Pulse Train Control
Mode
• Differential pulse input (MAX.200Kpps)
• Home return function
• Zone signal output: 2 point
(Note 1)
• No feedback pulse output
PIO
Pattern 7
7
Pulse Train Control
Mode
• Setting the datum point (1 places)
• Differential pulse input (MAX.200Kpps)
• Home return function
• Zone signal output: 1 point
(Note 1)
• No feedback pulse output
Note 1 Position zone signal can be switched to either ZONE signal in the setting of Parameter
No. 149
2.2 Operation Modes and Functions
ME0342-4B 2-9
2.2.4 Field Network Operation Modes and Features
In the field network, there are following operation modes available to select from and used for
operation. (Motion network excluded)
Operation should be made by writing the data necessary for operation (target position, velocity,
acceleration, pressing current, etc.) to the specified addresses from a host connected device
such as PLC.
[1] Operation Modes and Functions
The field network type PCON-CB/CFB/CBP should make operation by selecting a mode from
the following eight operation modes.
Key function
Remote
I/O mode
Position/
simple
direct
mode
Half direct
mode
Full direct
mode
Remote I/O
mode 2
Position/
simple
direct
mode 2
Half direct
mode 2
Remote I/O
mode 3
Number of occupied
bytes
2 8 16 32 12 8 16 12
Operation by position
data specification
x 
(*1)
 
x 
(*1)

x
Direct
speed/acceleration
specification
x x
 
x x

x
Push-motion operation
       
Current position read x
      
Current speed read x x
 
x x

x
Operation by position
number specification
 
x x
 
x

Completed position
number read
 
x x
 
x

Maximum position table
size
512 768 Not used Not used 512 768 Not used 512
Force Control
(
*
2)
△
(*3)
x x

△
(*3)
 
△
(*3)
(*1) The actuator is operated by specifying all position data, other than positions, using position
numbers.
(*2) The force control is a feature available for use only in the PCON-CBP/CGBP.
(*3) It is available for use in the PCON-CBP/CGBP when 6 or 7 is set in PIO Pattern.
(*) Position/Simple Direct Mode 2, Semi Direct Mode 2 and Remote I/O Mode 3 should be
available to select only in PCON-CBP/CGBP.
