IAI PCON-CB series User Manual

4. Operation
4.2 Operation in Positioner Mode
4-62
ME0342-4B
Caution
● At occurrence of an alarm in the release level, RES can reset the alarm. Cancel the
remaining moving distance after confirmation that alarm signal *ALM (being ON in
normal state and OFF at occurrence of an alarm) is set to ON.
* Refer to [8.3.3 Alarm Details] for details of alarms.
● Turning *STP OFF with the actuator being in the positioning complete state causes
PEND to be turned OFF. Note that this situation may not occur when a sequence
program is created. It is not an emergency stop output due to an alarm generation of the
controller.
Before operation
Positioning complete state
Operation
Temp.
stop
Cont.
Op.
Position
complete
Pause signal *STP
(PLC→Controller)
PEND
(Controller
→
PLC)
Moving Signal MOVE
(Controller→PLC)
Turning RES ON here allows
continuous operation to be cancelled
Operation of actuator
PEND turned
OFF
PEND not
turned ON
4.2 Operation in Positioner Mode
ME0342-4B 4-63
4.2.6 Direct Position Specification (Operation of PIO Pattern 4 and 7)
The start signal is provided for every position number. Only turning ON the relevant input signal
according to the table shown below allows the operation based on the data in the target position
number to be performed. The operation mode is called the solenoid valve mode because
solenoid valves can directly drive air cylinders.
At the completion of positioning, every completed position number is output as well as the
positioning complete signal.
Positioning, pressing, and pitch feed are possible. Their control methods are the same as those
of other patterns.
[1] Positioning [Basic] (ST0 to ST6, PE0 to PE6, PEND)
PIO Pttern 4 (ST0 to ST6, PE0 to PE6 and PEND)
Position No.
Input
Output
0
ST0
PE0
PEND
1
ST1
PE1
PEND
2
ST2
PE2
PEND
3
ST3
PE3
PEND
4
ST4
PE4
PEND
5
ST5
PE5
PEND
6
ST6
PE6
PEND
PIO Pttern 7 (ST0 to ST4, PE0 to PE4 and PEND)
Position No.
Input
Output
0
ST0
PE0
PEND
1
ST1
PE1
PEND
2
ST2
PE2
PEND
3
ST3
PE3
PEND
4
ST4
PE4
PEND
Note • Speed change is not allowed during movement.
• For incremental type, if start signal ST* is issued without home return, the home
return operation is automatically done before the operation based on the data of the
specified position number. When this specification is not desired, interlock by home
return complete signal HEND is required.
• In the battery-less absolute or simple absolute type, if it gets into a condition that the
home-return operation is incomplete due to such a reason as a parameter change,
operation to the indicated position number would not be performed, but only the
home-return operation should be performed.
