IAI PCON-CB series User Manual

2. Specications
2.2 Operation Modes and Functions
2-8 ME0342-4B
2.2.3 Pulse Train Control Mode (PCON-CB/CBP I/O Type: PLN and PLP)
Switching between the positioner mode and the pulse train control mode should be available in
the parameters for the pulse train control type (I/O type PLN and PLP) in PCON-CB.
There are two types of control systems in the pulse train control mode. Set the most suitable
PIO pattern in Parameter No. 25 "Select PIO Pattern".
Also, switching between the positioner mode and the pulse train control mode should be
available in the parameters for the pulse train control type of PCON-CB. There should be six
types of PIO patterns available to select from in accordance with the parameters in the
positioner mode.
Refer to [3.2.3 Wiring] for wiring in the pulse train control and [4.3 Pulse Train Control Mode] for
details of how to operate and the main features.
[1] PIO Patterns in Pulse Train Control Mode
Pattern
type
Value set in
Parameter
No.25
Mode Overview
PIO
pattern 0
0
Positioning mode
(Standard type)
Refer to [2.2.2 Positioner Mode (PCON-
CB/CBP I/O Type: NP and PN)]
PIO
pattern 1
1
Teaching mode
(Teaching type)
PIO
pattern 2
2
256-point mode (256-
point type)
PIO
pattern 3
3
512-point mode (512-
point type)
PIO
pattern 4
4
Solenoid valve mode 1
(7-point type)
PIO
pattern 5
5
Solenoid valve mode 2
(3-point type)
PIO
pattern 6
6
(Factory default)
Pulse Train Control
Mode
• Differential pulse input (MAX.200Kpps)
• Home return function
• Zone signal output: 2 point
(Note 1)
• No feedback pulse output
PIO
Pattern 7
7
Pulse Train Control
Mode
• Setting the datum point (1 places)
• Differential pulse input (MAX.200Kpps)
• Home return function
• Zone signal output: 1 point
(Note 1)
• No feedback pulse output
Note 1 Position zone signal can be switched to either ZONE signal in the setting of Parameter
No. 149
