6. Parameter
6.1 Parameter
6-7 ME0342-4B
6.1.2 Parameter Details
Caution
After changing (writing) parameters, perform a software reset or power reboot so that the
set values can be reflected.
The unit (deg) is applicable to the rotary actuator or lever-type gripper. Note that it will
be displayed as millimeter [mm] on the teaching tool.
[1] Zone Boundary 1 + Side, Zone Boundary 1 - Side (Parameter No. 1, No. 2)
Zone Boundary 2 + Side, Zone Boundary 2 - Side (Parameter No. 23, No. 24)
No. Name Unit Input range
Default initial value
setting
1 Zone boundary 1 + side
mm
(deg)
-9,999.99 to 9,999.99
Actual stroke on +
side
2 Zone boundary 1 - side
mm
(deg)
-9,999.99 to 9,999.99
Actual stroke on -
side
23 Zone boundary 2 + side
mm
(deg)
-9,999.99 to 9,999.99
Actual stroke on +
side
24 Zone boundary 2 - side
mm
(deg)
-9,999.99 to 9,999.99
Actual stroke on -
side
These parameters are used set the zone in which zone signal (ZONE1 or ZONE2) turns ON in a
mode other than PIO patterns 1 to 3.
The minimum setting unit is 0.01mm (deg).
If a specific value is set to both zone boundary + and zone boundary -, the zone signal is not
output.
A setting sample is shown below.
