4. Operation
4.4 Operation of Field Network Type
4-128
ME0342-4B
4.4 Operation of Field Network Type
In the field networks, the following operation modes are available to choose from for operation.
(Except for the motion network)
Operation should be made with the data necessary for operation (such as target position,
velocity, acceleration, pressing current, etc.) written in the determined addresses from such as
PLC connected to the host.
For details regarding operation of each field network, refer to the instruction manuals listed below.
PCON-CB/CFB/CBP Type
Field Network
Name
Description Details
Supported models
CB/CFB CBP
CC-Link
Control of the actuator is available
with I/O communication using the
control signals same as those for
PIO or the numerical data
communication.
Refer to the other
ME0254
(Note 1)
○ ○
CC-Link IE Field
Refer to the other
ME0389
(Note 1)
○ ○
CompoNet
Refer to the other
ME0220
(Note 1)
○ ○
DeviceNet
Refer to the other
ME0256
(Note 1)
○ ○
EtherCAT
Refer to the other
ME0273
(Note 1)
○ ○
EtherNet/IP
Refer to the other
ME0278
(Note 1)
○ ○
MECHATROLINK-I/II
Refer to the other
ME0221
(Note 1)
○ ○
PROFIBUS-DP
Refer to the other
ME0258
(Note 1)
○ ○
PROFINET IO
Refer to the other
ME0333
(Note 1)
○ ○
MECHATROLINK-III
Synchronized control of several
actuators in highly constant
periodicity is available.
Refer to the other
ME0317
(Note 1)
○ ×
RS485
Actuator is controlled with using a
general protocol “Modbus”
communication.
Refer to the other
ME0162
(Note 1)
○ ○
Note 1 PCON-CB/CFB/CBP are the slave units (slave stations).
Refer to the instruction manual of the master unit of each supplier and PLC to be
mounted for the details of each network.
For the instruction of the field network for PCON-CB/CFB/CBP, the instruction manual is
provided separately. Use the manual together with this manual.
Note 2 PCON-CBP is not applicable for MECHATROLINK-III.
4.5 Absolute Reset
ME0342-4B 4-129
4.5 Absolute Reset
In Simple Absolute Type and Battery-less Absolute Type, the encoder position information is
retained even when the power is OFF. For those types, it is unnecessary to perform home-
return operation every time the power is turned ON.
For Simple Absolute Type registers the home position in the cases of (1) to (3) (absolute reset)
to retain.
(1) At initial startup
(2) When the absolute battery was replaced with the power to the controller is shut, and
(3) Disconnection of encoder cable from controller
Battery-less Absolute Type registers the home position in the cases of (1) and (2) stated below.
(1) At motor replacement
(2) When absolute error generated
Refer to [2.6.2 Absolute Battery • Absolute Battery Unit] for the specifications of the absolute
battery and absolute unit.
For how to replace an absolute battery or absolute unit, check in [7.4.1 Replacement of Absolute
Battery].
