IAI PCON-CB series User Manual

4. Operation
4.2 Operation in Positioner Mode
4-34 ME0342-4B
[7] Binary Output of Alarm Data Output (*ALM, PM1 to 8)
PIO signal
Output
*ALM
PM1 to 8
Common to
Patterns 0 to 3
 
Pattern 4
(Note 1)

×
Pattern 5
(Note 1)

×
Pattern 6
 
Pattern 7
(Note 1)

×
: Available, ×: Unavailable
Note 1 Patterns 4, 5 and 7 do not have this function.
1) If an alarm at a level equal to or higher than the operation release level occurs, completed
position number output signals PM1 to PM8 output the alarm information in the binary code
format.
2) The PLC can read the binary code of alarm signal *ALM as the strobe signal to refer to alarm
information.
Refer to [8.3.1 Simple Alarm Codes] for details of the binary codes.
