Revision history
10 Warranty
10-3
ME0342-4B
Revision history
ME0342-4B Post-1
Revision history
Revision date Revised content
2016.01
2016.03
2016.11
2018.02
First Edition
1B Edition
P20, 168 Change made to applicable teaching
P231 Correct made e-CON model
1C Edition
[1], [2], … added to Table of Contents
Starting Procedures Ladder Edit Program deleted
P11 Change made to International Standards Compliance
P19 Note added in remark of 5 Dummy Plug saying “Only when
PCON-CGB/CGFB”
P21, 157, 219 MECHATROLINK- added
P22 Rated load current for PCON-CFB/CGFB deleted
P23 Note added stating weight of battery and battery case should be
added for simple absolute type
P47, 61, 205 RCP6 added
P65 Correct made from BKRLS to BK
P71, 73 Figure swapped
P80 Caution note added for first order lag filter
P90 Note added stating detection range of zone signal depends on
number of encoder pulse
Note added stating it differs depending on models
P107, 122 Explanation added for TRQS signal timing change
P114 Change made to Description 4) ON → OFF
P115 ST1 to ST6 → ST0 to ST6, PE1 to PE6 → PE0 to PE6
P147, 148 Table added and corrected for binary output in [10] Binary
Output of Alarm Data Output
P154 [3] Pulse Train Datum Position added
P166 6.2 Automatic Current Reduction Feature added
P179 Signal changed to
in “For Pulse Train Mode” in high-output
setting
No. 182 Automatic current reduction feature select added
P179, 208 Pulse train datum position range changed from 0 to 9999.99 to -
9999.99 to 9999.99
Others Correction made
1D Edition
P24 to 29 Correction made to dimensions in Appearance
P49 Correction made to signal names for 8B and 9B in PIO Pattern 1
P42, 128 Explanation added for ST0 and TRQS Signals in Solenoid
Valve Mode 2
P9, 265 Note added and changed in cause for Pulse Train Control Mode
