3. Wiring

3.1 Positioner Mode (PIO Control)

3-15 ME0342-4B

[2] Connecting the motor/encoder cable

1) Connection to RCP2 Series

2) Connection to RCP3, RCP4, RCP5 and RCP6 Series

PCON

Motor/Encoder

Connector

Connection Cable

PCON

Motor/Encoder

Connector
