IDEC MICRO3 User Manual

1: GENERAL INFORMATION
1-6 USER’S MANUAL
General Specifications, continued
Operating Temperature 0 to 60°C
Storage Temperature –25 to +70°C
Relative Humidity Relative humidity severity level RH1, 30 to 95% (non-condensing)
Pollution Degree 2 (IEC 664)
Corrosion Immunity Free from corrosive gases
Altitude
Operation: 0 to 2,000m (0 to 6,565 feet)
Transport: 0 to 3,000m (0 to 9,840 feet)
Vibration Resistance
(IEC 68-2-6)
5 to 55 Hz, 60 m/sec
2
, 2 hours each in 3 axes
Shock Resistance
(IEC 62-2-27)
300 m/sec
2
, 11 msec, 3 shocks each in 3 axes
I/O Duty Ratio
All specification values are determined at an I/O duty ratio of 100% for the 10-I/O type and
at an I/O duty ratio of 80% for the 16- and 24-I/O types
Wiring
Core wire 0.75 to 1.25 mm
2
(AWG18 to AWG16)
Input lines must be separated from power, output, and motor lines
M3 screw terminal
Degree of Protection IP40 (IEC 529), provided with finger protection covers
Installation
35-mm-wide DIN rail and wall mount
In either case, MICRO
3
must be mounted on a vertical plain
Dimensions
105W × 85H × 60D mm — 4.134"W × 3.346"H × 2.362"D (10-I/O type)
135W × 85H × 60D mm — 5.315"W × 3.346"H × 2.362"D (16-I/O type)
165W × 85H × 60D mm — 6.496"W × 3.346"H × 2.362"D (16-I/O AC input type)
165W × 85H × 60D mm — 6.496"W × 3.346"H × 2.362"D (24-I/O type)
Weight
MICRO
3
Approx. 290g (10-I/O type)
Approx. 350g (16-I/O type)
Approx. 390g (16-I/O AC input type)
Approx. 400g (24-I/O type)
MICRO
3
C
Approx. 380g (16-I/O type)
Approx. 430g (24-I/O type)
Standards
MICRO
3
EN61131-1, EN61131-2, EN60204-1
IEC801-2, -3, -4
PrEN50082-2, EN55011
UL508, CSA C22.2 No. 142
MICRO
3
C
EN55011 Group 1, Class A
EN50082-2
UL508, CSA C22.2 No. 142
EN61131-1, EN61131-2, EN60204-1
Certification File No.
MICRO
3
TÜV Product Service E9 95 09 13332 313
UL E102542
CSA LR66809
MICRO
3
C
TÜV Product Service B950913332
UL E102542
CSA LR66809
