Intel S2600CP User Manual

Appendix C: LED Decoder
Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide (Preliminary) 165
Checkpoint
Diagnostic LED Decoder
Description
1 = LED On, 0 = LED Off
Upper Nibble Lower Nibble
MSB LSB
8h 4h 2h 1h 8h 4h 2h 1h
LED # #7 #6 #5 #4 #3 #2 #1 #0
31h 0 0 1 1 0 0 0 1 Memory Installed
32h 0 0 1 1 0 0 1 0 CPU PEIM (Cpu Init)
33h 0 0 1 1 0 0 1 1 CPU PEIM (Cache Init)
34h 0 0 1 1 0 1 0 0 CPU PEIM (BSP Select)
35h 0 0 1 1 0 1 0 1 CPU PEIM (AP Init)
36h 0 0 1 1 0 1 1 0 CPU PEIM (CPU SMM Init)
4Fh 0 1 0 0 1 1 1 1 Dxe IPL started
DXE Phase
60h 0 1 1 0 0 0 0 0 DXE Core started
61h 0 1 1 0 0 0 0 1 DXE NVRAM Init
62h 0 1 1 0 0 0 1 0 SB RUN Init
63h 0 1 1 0 0 0 1 1 Dxe CPU Init
68h 0 1 1 0 1 0 0 0 DXE PCI Host Bridge Init
69h 0 1 1 0 1 0 0 1 DXE NB Init
6Ah 0 1 1 0 1 0 1 0 DXE NB SMM Init
70h 0 1 1 1 0 0 0 0 DXE SB Init
71h 0 1 1 1 0 0 0 1 DXE SB SMM Init
72h 0 1 1 1 0 0 1 0 DXE SB devices Init
78h 0 1 1 1 1 0 0 0 DXE ACPI Init
79h 0 1 1 1 1 0 0 1 DXE CSM Init
90h 1 0 0 1 0 0 0 0 DXE BDS Started
91h 1 0 0 1 0 0 0 1 DXE BDS connect drivers
92h 1 0 0 1 0 0 1 0 DXE PCI Bus begin
93h 1 0 0 1 0 0 1 1 DXE PCI Bus HPC Init
94h 1 0 0 1 0 1 0 0 DXE PCI Bus enumeration
95h 1 0 0 1 0 1 0 1 DXE PCI Bus resource requested
96h 1 0 0 1 0 1 1 0 DXE PCI Bus assign resource
97h 1 0 0 1 0 1 1 1 DXE CON_OUT connect
98h 1 0 0 1 1 0 0 0 DXE CON_IN connect
99h 1 0 0 1 1 0 0 1 DXE SIO Init
9Ah 1 0 0 1 1 0 1 0 DXE USB start

Intel S2600CP Specifications

General

Processor Support	Intel Xeon processor E5-2600 product family
Chipset	Intel C602
Memory Slots	24 DIMM slots
Form Factor	SSI EEB (12" x 13")
Storage	Up to 8 SATA/SAS drives
Network	Dual Gigabit Ethernet
CPU Socket Type	LGA 2011
SATA	SATA II and SATA III
RAID Support	RAID 0, 1, 5, 10
Network Controller	Intel 82574L
Power Supply	Redundant power supply support
Management	IPMI 2.0
