INVT SV-DA200 Series User Manual

SV-DA200 series AC servo drive Function codes
-117-
P1.25
1
st
notch filter depth
selection
Setting range
Default
Unit
Available mode
0–100
0
%
P
S
T
This parameter is used to set the amplitude attenuation rate of 1
st
notch filter.
When the setting value increases, the notch filter depth becomes shallow and phase lag will be smaller.
P1.25
Data size
16bit
Data format
DEC
Modbus address
1250, 1251
CANopen address
0x2119, 0x00
P1.26
2
nd
notch filter frequency
Setting range
Default
Unit
Available mode
50–5000
5000
Hz
P
S
T
P1.27
2
nd
notch filter Q value
Setting range
Default
Unit
Available mode
0.50–16.00
1.00
-
P
S
T
P1.28
2
nd
notch filter depth
selection
Setting range
Default
Unit
Available mode
0–100
0
%
P
S
T
Refer to P1.23, P1.24 and P1.25 for detailed parameters setting.
P1.26
Data size
16bit
Data format
DEC
Modbus address
1252, 1253
CANopen address
0x211A, 0x00
P1.27
Data size
16bit
Data format
DEC
Modbus address
1254, 1255
CANopen address
0x211B, 0x00
P1.28
Data size
16bit
Data format
DEC
Modbus address
1256, 1257
CANopen address
0x211C, 0x00
P1.29
3
rd
notch filter frequency
Setting range
Default
Unit
Available mode
50–5000
5000
Hz
P
S
T
P1.30
3
rd
notch filter Q value
Setting range
Default
Unit
Available mode
0.50–16.00
1.00
-
P
S
T
P1.31
3
rd
notch filter depth
selection
Setting range
Default
Unit
Available mode
0–100
0
%
P
S
T
Refer to P1.23, P1.24 and P1.25 for detailed parameters setting.
P1.29
Data size
16bit
Data format
DEC
Modbus address
1258, 1259
CANopen address
0x211D, 0x00
P1.30
Data size
16bit
Data format
DEC
Modbus address
1260, 1261
CANopen address
0x211E, 0x00
P1.31
Data size
16bit
Data format
DEC
Modbus address
1262, 1263
CANopen address
0x211F, 0x00
P1.32
4
th
notch filter frequency
Setting range
Default
Unit
Available mode
50–5000
5000
Hz
P
S
T
P1.33
4
th
notch filter Q value
Setting range
Default
Unit
Available mode
0.50–16.00
1.00
-
P
S
T
P1.34
4
th
notch filter depth
selection
Setting range
Default
Unit
Available mode
0–100
0
%
P
S
T
