SV-DA200 series AC servo drive Product overview
-12-
Remark:
(1)
: 17-bit absolute single turn motor belongs to a separate series and its dimension and parameters
are different. Only electromagnetic brake is used. Please pay attention to corresponding series when
selecting models;
(2)
: 40-base motor, only supports 2500-PPR and 17-bit absolute encoder;
(3)
: Non-stock up model, the ordering cycle will be delayed for 3–5 days;
(4)
: No need to fill in for the first-time model selection by customers;
In addition, the non-17 bit single-turn absolute motor with 40 or 60 base supports permanent magnet
brake only.
1.3 Cables
1.3.1 Nameplate of cables
67002-00351
5m power flexible towline cable,0.75mm cable
diameter,4PIN plastic plug,7PIN 20A plug
DAML-075-05-ABF-00
INVT INDUSTRIAL TECHNOLOGY(SHANGHAI) CO.,LTD.
上海英威腾工业技术有限公司
2
1.3.2 Naming of the power cables
DAML-075-05-ABF-00
① ② ③ ④ ⑤ ⑥ ⑦ ⑧
Symbol
Instruction
Naming instance

Product series
For internal use by manufacturer

Power cable
ML: Power cable

Cable diameter
075: 0.75mm
2
100: 1.0mm
2
150: 1.5mm
2
250: 2.5mm
2
400: 4.0mm
2
600: 6.0mm
2
