INVT SV-DA200 Series - P6 Application Function

SV-DA200 series AC servo drive Appendix
-278-
Function
code
Name
Unit
Range
Default
Available
Mode
P5.48
11 ACC/DEC time
ms
0–32767
3000
P
P5.49
12 ACC/DEC time
ms
0–32767
5000
P
P5.50
13 ACC/DEC time
ms
0–32767
8000
P
P5.51
14 ACC/DEC time
ms
0–32767
50
P
P5.52
15 ACC/DEC time
ms
0–32767
30
P
P5.53
00 delay time
ms
0–32767
0
P
P5.54
01 delay time
ms
0–32767
100
P
P5.55
02 delay time
ms
0–32767
200
P
P5.56
03 delay time
ms
0–32767
400
P
P5.57
04 delay time
ms
0–32767
500
P
P5.58
05 delay time
ms
0–32767
800
P
P5.59
06 delay time
ms
0–32767
1000
P
P5.60
07 delay time
ms
0–32767
1500
P
P5.61
08 delay time
ms
0–32767
2000
P
P5.62
09 delay time
ms
0–32767
2500
P
P5.63
10 delay time
ms
0–32767
3000
P
P5.64
11 delay time
ms
0–32767
3500
P
P5.65
12 delay time
ms
0–32767
4000
P
P5.66
13 delay time
ms
0–32767
4500
P
P5.67
14 delay time
ms
0–32767
5000
P
P5.68
15 delay time
ms
0–32767
5500
P
P5.69
PTP trigger buffer switch
-
0–1
1
P
P5.70
Single-turn resolution of disk
pulse
-(2
31
-1)–(2
31
-1)
10000
P
P5.71
Zero-returning switch of disk
-
0–3
0
P
P5.72
Multi-turn mode
-
0–1
0
P
P5.73
Digital trigger mode of PTP
-
0–1
0
P
P5.74
Digital output mode of PTP
-
0–4
0
P
P5.75
Enable interruption pause of the
point
-
0–1
0
P
P6 Application function
P6.00
Forward low JOG speed
r/min
0–6000
5
P
P6.01
Reverse low JOG speed
r/min
-6000–0
-5
P
P6.02
Position latch function switch
-
0–1
0
P
P6.03
Position latch save mode
-
0–1
0
P
P6.04
Forward high JOG speed
r/min
0–6000
60
P
P6.05
Reverse high JOG speed
r/min
-6000–0
-60
P
P6.06
Terminal JOG valid
-
0–1
1
P
P6.20
Turret function switch
-
0–1
0
P
