SV-DA200 series AC servo drive Installation instruction
-25-
2.3.4 Outline and installation dimension for 110 base (mm)
110
110
Φ130
6h9A-A
Φ95h7
2.5
40
Φ19h7
12
5
55 L
M6 depth 20
21.5
4-Φ9
Φ20×2
A
A
Motor model (2500-PPR/multi-turn
absolute value/rotary transformer)
L(mm)
W/o brake
Permanent magnet
brake
Electromagnetic
brake
SV-MM11-0R8E-2-A
189
245
263
SV-MM11-1R2G-2-A
SV-MM11-1R5G-2-A
204
260
278
SV-MM11-1R2E-2-A
219
275
293
SV-MM11-1R8G-2-A
