INVT SV-DA200 Series - Naming of the Encoder Cables

SV-DA200 series AC servo drive Product overview
-14-
Symbol
Instruction
Naming instance
E: 4PIN regular aviation plug YD18
N: 4PIN regular aviation plug YD32
S: Copper tube terminal SC

Plug on drive end
B: Euro 7PIN 20A plug
W: No plug
S: Copper tube terminal SC
1.3.4 Naming of the encoder cables
DBEL-15-03-AF-0100
① ② ③ ④ ⑤ ⑥ ⑦ ⑧
Symbol
Instruction
Naming instance

Product series
For internal use by manufacturer

Encoder cable
EL: Encoder cable

Cable number
06: 6-core cable
09: 9-core cable
15: 15-core cable

Cable length
03: 3m
05: 5m
10: 10m
……

Plug on motor end
A: 15PIN DB plug
B: 15PIN regular aviation plug YD28
C: 9PIN metal plug
D: 6PIN plastic head

Cable material
0: regular cable without battery holder
D: regular cable with battery holder
F: Flexible drag chain cable without battery holder
H: Flexible drag chain cable with battery holder

Encoder type
01: 2500-PPR standard incremental type
04: 17-bit single-turn/17-bit multi-turn/23-bit multi-turn
absolute value
07: Rotary transformer

Serial no.
00: Standard part
01: Serial no. for non-standard part
……
