SV-DA200 series AC servo drive Control mode applications
-62-
Signal name
Sign
Function number
Available mode
PTP output 2
PTPO2
0x18
P
This function is output PTP output 2 signal.
Signal name
Sign
Function number
Available mode
PTP output 3
PTPO3
0x19
P
This function is output PTP output 3 signal.
Signal name
Sign
Function number
Available mode
PTP output 4
PTPO4
0x1A
P
This function is output PTP output 4 signal.
Signal name
Sign
Function number
Available mode
PTP output 5
PTPO5
0x1B
P
This function is output PTP output 5 signal.
Signal name
Sign
Function number
Available mode
PTP output 6
PTPO6
0x1C
P
This function is output PTP output 6 signal.
Signal name
Sign
Function number
Available mode
PTP output 7
PTPO7
0x1D
P
This function is output PTP output 7 signal.
Signal name
Sign
Function number
Available mode
Gantry synchronization output clear
GSC
0x1E
P
This function is to output the clearance signal of gantry synchronization
Signal name
Sign
Function number
Available mode
Dynamic brake relay control
DBRC
0x1F
P
S
T
This function is output dynamic brake relay control signal.
4.4.5 Pulse input signals and functions
Sign
Pin no.
Name
Function
OCP
38
Position command
pulse input 1
 In the position control mode, act as the position
command input terminal.
 In other control mode, the terminal is invalid.
 Allowed Max. input pulse frequency: 4MHz in
differential motion mode, 200kHz in open-collector
mode.
PULS+
23
PULS-
24
OCS
31
Position command
pulse input 2
SIGN+
32
SIGN-
33
