SV-DA200 series AC servo drive Product overview
-15-
1.3.5 Naming of encoder cables fittings
DBEL-AA
① ② ⑨ ⑤
Symbol
Instruction
Naming instance

Product series
For internal use by manufacturer

Encoder cable
EL: Encoder cable

Plug on drive end
A: 15PIN DB plug

Plug on motor end
A: 15PIN DB plug
B: 15PIN regular aviation plug YD28
C: 9PIN metal plug
D: 6PIN plastic head
1.3.6 Naming of motor braking cables
BRKL-03-A
① ② ③
Symbol
Instruction
Naming instance

Product series
BRKL: motor brake cable

Cable length
03: 3m
05: 5m
10: 10m
30: 30m

Plug on motor end
A: 2PIN metal plug
B: 3PIN regular aviation plug
C: 3PIN metal plug
