INVT SV-DA200 Series - 17-Bit and 23-Bit 40, 60, 80 Base Encoder Cable; 17-Bit and 23-Bit 110, 130, 180, 200 Base Encoder Cable; Rotary Transformer Encoder Cable

SV-DA200 series AC servo drive Wiring instruction
-43-
3.5.4 17-bit and 23-bit 40, 60, 80 base encoder cable
B
7
6
5
4
3
2
1
8
9
X2
B direction view
A dire ction view
1
11
15
5
6
10
X1
A
Wiring relation
Signal
X1
X2
Core wire structure
SD+
X1.1
X2.1
Twisted pair
SD-
X1.7
X2.2
5V
X1.5
X2.3
Twisted pair
GND
X1.12
X2.4
VB-5V
/
X2.5
Twisted pair
VB-GND
/
X2.6
PE
Steel casing
Steel casing
Weaving
3.5.5 17-bit and 23-bit 110, 130, 180, 200 base encoder cable
12
35
610
11
13
1415
X2
B
B dire ction v iew
A direc tion view
1
11
15
5
6
10
X1
A
Wiring relation
Signal
X1
X2
Core wire structure
SD+
X1.1
X2.2
Twisted pair
SD-
X1.7
X2.3
5V
X1.5
X2.4
Twisted pair
GND
X1.12
X2.5
VB-5V
/
X2.6
Twisted pair
VB-GND
/
X2.7
PE
Steel casing
X2.1
Weaving
3.5.6 Rotary transformer encoder cable
12
3
5
610
11
13
1415
X2
B
A dir ec tion view
B dire ction v iew
1
11
15
5
6
10
X1
A
Wiring relation
Signal
X1
X2
Core wire structure
SIN+
X1.1
X2.6
Twisted pair
SIN-
X1.7
X2.7
COS+
X1.2
X2.5
Twisted pair
COS-
X1.8
X2.4
R+
X1.5
X2.3
Twisted pair
R-
X1.12
X2.2
PE
Steel casing
X2.1
Weaving
