SV-DA200 series AC servo drive Function codes
-161-
signal setting; for 1/1 width encoder, the set Z type must be the AB value corresponds to the
middle of high level.
P4.70
1
Data size
16bit
Data format
DEC
Modbus address
1940, 1941
CANopen address
0x2446, 0x00
P4.78
1
MotionNet node number
Setting range
Default
Unit
Available mode
0–63
0
-
P
S
T
Set communication node number of local machine (slave station) in MotionNet communication.
P4.78
1
Data size
16bit
Data format
DEC
Modbus address
1956, 1957
CANopen address
0x244E, 0x00
P4.79
1
MotionNet baud rate
Setting range
Default
Unit
Available mode
0–3
2
-
P
S
T
Set MotionNet baud rate as follows:
Setting value
Baud rate
0
2.5Mbps
1
5.0Mbps
[2]
10.0Mbps
3
20.0Mbps
P4.79
1
Data size
16bit
Data format
DEC
Modbus address
1958, 1959
CANopen address
0x244F, 0x00
P4.80
Configuration of PZD
setting parameter 1
Setting range
Default
Unit
Available mode
1000–3999
1998
-
P
S
T
This parameter is used to set the mapping content of setting parameter 1 in PROFIBUS-DP
communication (1998 corresponds to the reserved parameters).
P4.80
Data size
16bit
Data format
DEC
Modbus address
1960, 1961
CANopen address
0x2450, 0x00
P4.81
Configuration of PZD
setting parameter 2
Setting range
Default
Unit
Available mode
1000–3999
1998
-
P
S
T
This parameter is used to set the mapping content of setting parameter 2 in PROFIBUS-DP
communication (1998 corresponds to the reserved parameters).
P4.81
Data size
16bit
Data format
DEC
Modbus address
1962, 1963
CANopen address
0x2451, 0x00
P4.82
Configuration of PZD
setting parameter 3
Setting range
Default
Unit
Available mode
1000–3999
1998
-
P
S
T
This parameter is used to set the mapping content of setting parameter 3 in PROFIBUS-DP
communication (1998 corresponds to the reserved parameters).
P4.82
Data size
16bit
Data format
DEC
Modbus address
1964, 1965
CANopen address
0x2452, 0x00
