SV-DA200 series AC servo drive Product overview
-11-
Symbol
Instruction
Naming instance
0R7: 750W
0R8: 800W/850W
1R0: 1.0kW
1R2: 1.2kW
1R3: 1.3kW
1R5: 1.5kW
1R8: 1.8kW
2R0: 2.0kW
3R0: 3.0kW
4R4: 4.4kW
5R5: 5.5kW
7R5: 7.5kW
011: 11kW
015: 15kW
022: 22kW
037: 37kW
045: 45kW
055: 55kW
……

Rated speed
A: 1000rpm
B: 1500rpm
E: 2000rpm
F: 2500rpm
G: 3000rpm

Voltage class
2: 220VAC
4: 380VAC

Encoder type
1: 2500-PPR standard incremental type
3: 17-bit single-turn absolute value
(1)
4: 17-bit multi-turn absolute value
7: Rotary transformer
9: 23-bit multi-turn absolute value

Shaft end
connection
A: solid with threaded hole and key (standard)
B: Solid optical axis

Optional part
0: with oil seal but no brake
1: without oil seal or brake
(3)
2: with oil seal and permanent magnet brake
3: without oil seal but with permanent magnet brake
(3)
4: with oil seal and electromagnetic brake
5: without oil seal but with electromagnetic brake
(3)
⑪
Lot no.
Manufacturer lot no.
(4)
