SCPI Conformance Information
J-9
:OUTPut
:TTL3
:LSENse <name>
:LSENse?
:TTL4
:LSENse <name>
:LSENse?
:ROUTe
:SCAN
[:INTernal]
:FUNCtion? <list>, <name>
:FUNCtion? <list>
:EXTernal <list>
:EXTernal?
:FUNCtion? <list>, <name>
:FUNCtion? <list>
:RATio
:RCHannel <list>
:RCHannel?
:MCHannel <list>
:MCHannel?
:DELTa
:RCHannel <list>
:RCHannel?
:MCHannel <list>
:MCHannel?
:LSELect <name>
:LSELect?
[:SENse[1]]
:ALTernate[1]
:SAVE
:RECall
:CURRent:AC
:APERture
:AUTO <b>
:AUTO ONCE
:AUTO?
:NPLCycles
:AUTO <b>
:AUTO ONCE
:AUTO?
:COUPling AC|DC
:COUPling?
:RANGe
:AUTO
:ULIMit <n>
:ULIMit?
:LLIMit <n>
:LLIMit?
:REFerence
:ACQuire
Path to set polarity of digital output line 3:
Select polarity; active (AHIGH) or active (ALOW).
Query polarity of line 3.
Path to set polarity of digital output line 4:
Select polarity; active (AHIGH) or active (ALOW).
Query polarity of line 4.
Command path to configure and control scan operations:
Specify an internal scan list (2 to 10 channels).
Assign measurement function to specified channels.
Query function for each specified channel.
Specify an external scan list (2 to 80 channels).
Query the external scan list.
Assign measurement function to specified channels.
Query function for each specified channel.
Command path to configure ratio calculation:
Specify reference channel (1 to 10).
Query reference channel.
Specify measure channel (1 to 10).
Query measure channel.
Command path to configure delta calculation:
Specify reference channel (1 to 10).
Query reference channel.
Specify measure channel (1 to 10).
Query measure channel.
Select scan operation: INTernal, EXTernal, RATio, DELTa, NONE.
Query scan operation.
Path to control an Alternate setup.
Save current setup as Alternate setup.
Return instrument to Alternate setup.
Path to configure AC current.
Specify integration rate in seconds (166.67e-6 to 200e-3).
Enable (1 or ON) or disable (0 or OFF) auto aperture.
Enable and then disable auto aperture.
Query auto aperture (0 or 1).
Specify integration rate (number of line cycles; 0.01 to 10).
Enable (1 or ON) or disable (0 or OFF) auto NPLC.
Enable and then disable auto NPLC.
Query auto line cycle integration (0 or 1).
Specify input coupling.
Query input coupling.
Path to configure measurement range:
Set range based on present input signal.
Specify upper limit for auto range (0 to +2.1).
Query upper limit.
Specify lower limit for auto range (0 to +2.1).
Query lower limit.
Specify reference (REL) value (-2.1 to +2.1).
Use input signal as reference.
Table J-2 (cont.)
Syntax of non-SCPI commands implemented by Model 2001
Command Description
