Keysight B1505A Configuration and Connection Guide 7-41
Connection and Ordering Examples
Configuration Examples for Lateral Device Measurement with Wafer Prober
N1265A 1 Ultra High Current Expander/Fixture
N1265A-001 1 Ultra High Current Expander/Fixture
16493S 1 High Current Source Monitor Unit Cable
16493S-011 1 High Current Source Monitor Unit non-Kelvin Adapter
16493U 1 High Current BNC Coaxial Cable
16493U-001 3 High Current BNC Coaxial Cable (1.5 m)
1250-2405 1 BNC-T plug (m)-BNC (f)-BNC (f) adapter, 1ea
N1260A 1 High Voltage Bias-Tee
N1260A-STD 1 High Voltage Bias-Tee
N1254A 1 Accessories for instruments and fixtures
N1254A-524 1 Ultra High Current Prober System Cable
N1254A-104 1 Triax (f) to BNC (m) adapter
N1254A-518 3 SHV Cable 1.5 m
N1262A 1 R-box for B1505A
N1262A-036 1 50 Ohm Termination Adapter
