1-36 Keysight B1505A Configuration and Connection Guide
Configuration Guide
N1271A Thermal Test Enclosure and Related Accessories
Table 1-15 N1271A Thermal Test Enclosure Options and Related Accessories
Model/Option Description Additional Information
N1271A Thermal Test Enclosure
N1271A-001 Thermal Plate Compatible Enclosure for
N1259A/N1265A
• Accessory for the N1259A/N1265A test
fixture for using the inTEST Thermal
Plate to enable temperature dependency
measurements up to +250 C.
• Contains the N1254A-557 connection kit.
• Inner dimension is 284 mm W, 340 mm
H, 195 mm D.
N1271A-002 Thermostream Compatible Enclosure for
N1265A (3 kV IV)
• Interface between the N1265A and the
inTEST Thermostream. The enclosure
supports fully automated IV
measurements up to 3 kV at temperature
range from -50 C to +220 C.
• Contains the N1254A-557 connection kit.
• Inner dimension is 284 mm W, 150 mm
H, 195 mm D.
To Next Page
