Section 1 Basic Printer Functions 1-9
1. 5. 2 Rear view
No. Name Function
1 Exit Cover Open the Exit Cover when you remove the paper
mis-fed inside of the Fuser Unit.
2 LAN Port Connect the LAN Cable here to connect the KIP3000 to
the network. (Do not connect a telephone line.)
Note:
There may also be a serial port in this area for folder
connection ( optional device )
3 Dehumidify Heater Switch
(Option)
Turn on the Dehumidify Heater with this switch when you
would like to dry the paper in the humid season.
4 Inlet Socket Connect the Power Cord here.
5 Breaker It is possible to shut off supplying the AC power.
6 Print Guide Trays These trays guide the prints to the Print Tray.
1
6
2
3
4
5
