Kohler KDI 1903 TCR Workshop Manual

EN
80
Before switching the engine off after intense
activity, one must allow the turbocharger to cool
down. One must therefore let the engine run at
idle speed or without a load for at least 2 minutes,
thus allowing the turbocharger to cool.
5.
Engine at idle speed
Avoid using the engine at idle speed or without a
load for long periods (more than 20-30 minutes).
When operating at idle speed or without a load,
the turbocharger is at low pressure in the exhaust
chamber C and air supply D ; this may cause oil
leaks from seals E
to the extremity of the shaft. Even if this does not
cause damage, it can cause blue smoke from the
exhaust when the engine speed and load are
increased.
2.18.3 Before installing a new turbocharger
Important

Do not lift the turbocharger with one hand from
the box.

Do not lift turbocharger from Comp hsg side.

Lift the turbocharger with both hands from box.

Make sure to use clean gloves.

Handle the turbocharger as indicated in Par.
2.17.4.
Fig 2.62
1.
Avoid lifting from the intake side G .
2.
Remove cap guard F and check that there is no
excessive shaft axial and radial clearances.
Fig 2.63
1.
Check for any signs of friction of the turbine on
the turbocharger body.
2.
Check for any traces of oil leaks on the
turbocharger body.
3.
After having check everything, reapply cap F on
intake opening H of the turbocharger and do not
remove it until assembly has been completed.
Fig 2.64
