DETAILED CONTROLS AND GAUGES OPERATION
3-88
Room Lamp Switch (front of engine room)
It is possible to turn on the interior cab room lamp even when starting switch is in the OFF position, do not
forget to turn it off.
Use this switch (23) to light up the room lamp inside the engine
room.
ON position: Lights up
OFF position: Goes out
Room Lamp Switch (rear of engine room)
It is possible to turn on the interior cab room lamp even when starting switch is in the OFF position, do not
forget to turn it off.
Use this switch (24) to light up the room lamp inside the engine
room.
ON position: Lights up
OFF position: Goes out
Room Lamp Switch (pump room)
It is possible to turn on the interior cab room lamp even when starting switch is in the OFF position, do not
forget to turn it off.
Use this switch (25) to light up the room lamp inside the pump
room.
ON position: Lights up
OFF position: Goes out
