DETAILED CONTROLS AND GAUGES OPERATION
3-14
Caution Monitors 3
If the warning monitor flashes, check the problem point as soon as possible and carry out maintenance.
Failure to repair the problem may cause to failure of the machine.
These are items which need to be observed while the engine is running. If any problem occurs, items which need
to be repaired as soon as possible are displayed.
If there is any problem, the appropriate monitor lamp will flash to indicate the location of the problem.
(*): Displayed in center of screen in same way as for (1) (3) and (9)
(1) Charge level monitor (6) PTO temperature monitor
(2) Fuel level monitor (7) Engine oil temperature monitor
(3) Air cleaner clogging monitor (8) Grease level monitor
(4) Engine water temperature monitor (9) Auto greasing abnormality monitor
(5) Hydraulic oil temperature monitor (10) Hydraulic oil filter clogging monitor(*)
