ATTACHMENTS AND OPTIONS HANDLING SERVICE CENTER
6-19
METHOD OF DRAINING, ADDING LUBRICANT AND COOLANT FROM
SERVICE PANEL 6
A force-feed pump and force-feed pump coupler are needed to carry out draining or adding lubricant and coolant
from each coupler of the service center.
q Couplers manufactured by WIGGINS are used for each coupler of the service center. When preparing a cou-
pler for the force-feed pump, use the equivalent of the WIGGINS part number in the chart below.
Komatsu does not handle force-feed pumps, but if a force-feed pump coupler is needed, please consult your
Komatsu distributor.
q Before connecting the service center coupler and force-feed pump coupler, wipe off all dirt, oil, or
other foreign material from each coupler to prevent dirt from getting inside the piping.
q When adding lubricant and coolant, always check that the amount is the specified amount.
Unit coupler (Service center side) coupler (force-feed pump side)
Engine oil coupler ON2 OS2
Swing machinery oil (rear) coupler ON2 OS2
Swing machinery oil (front) coupler ON2 OS2
PTO oil coupler ON2 OS2
Hydraulic oil coupler 6005A12 6005B12
Coolant coupler EC285A8 EC280B8
Fuel coupler ZN2B ZZ9A1
Grease coupler OS2 ON2
